1. product advantage
Pure imported high-temperature quartz pipe, high transmittance, easy installation, low working temperature, good wind pressure resistance, UV output stability, good adaptability

2. application scope / usage scenario
It is mainly used in small test machinery, UV glue curing, aging test and so on.


Model	Power W	Length mm	Luminous long mm	Voltage	Installation method	Line length
T-UV-0123	1000	230	130	220	Porcelain head or Copper head A2	210
T-UV-0130	1000	300	200	220	Porcelain headA3	210
T-UV-0240D	2000	400	250	220/380	Copper head D1
T-UV-0240	2000	400	250	220/380	Porcelain head A1	210
T-UV-0362	3000	620	500	380	Porcelain head A1	210
T-UV-36/300	3600	400	300	220/380	Porcelain head A3	100
T-UV-48/300	4800	400	300	220/380	Porcelain head A3	100
T-UV-50/270	5000	355	270	220/380	Porcelain head A3	100
T-UV-00575	5000	750	630	380	Porcelain head A1	210
T-UV-05682	5600	826	700	380	Porcelain head A1	210
T-UV-056105	5600	1050	930	380	Porcelain head A1	210

Power: 1KW
Total length and luminous length: 230mm/125mm
Pipe diameter: 25mm
Voltage: 220V
Installation: Porcelain lead / copper top type.
Spectral peak: 365nm
Main material: imported high temperature resistant quartz tube.
Inventory: spot
Quality assurance: 800 hours.
UV energy: single lamp 223MJ/4 meters
Ambient temperature: 60-80 degrees Celsius

1KW UV lamp routine parameter list
Full length / long luminous length mm voltage installation mode
1 1000W 200/100 220V porcelain lead wire
2 1000W 230/130 220V porcelain lead / copper top type
3 1000W 300/200 220V porcelain lead wire
4 1000W 330/230 220V porcelain lead wire
5 1000W 400/250 220V porcelain lead wire
6 1000W 460/340 220V porcelain lead wire
7 1000W 540/420 220V porcelain lead wire
