1. Automatic production of core components to maintain consistency of quality and quality.
2, R & D for many years to form a unique production process.
3, module 100% test, whole machine 100% continuous 72 hours lighting test.
I. compact design
The smallest size with the same power, excellent heat dissipation, strong power; flexible installation mode, according to customer needs customized installation holes.
Two. Radiant power 10%-100% stepless adjustment
1. It can adjust the power according to the change of environment climate, ink, paint and ink to achieve the best curing effect.
2. Especially suitable for applications with different curing requirements, such as semi-dry backing coating can save more electricity;
3. can adjust the power compensation light decay, extend the product life.
4. provide manual / automatic adjustment options.
Three. Professional development of the drive control system.
1.PWM constant current power supply and DC constant current power supply mode are optional, and the operation of the products is more stable.
2. achieve real millisecond switch, without affecting the system life and no curing delay.
3. perfect alarm system to ensure the efficiency of equipment operation and low reject rate.
4. A variety of power supply and control systems are available for selection, such as switching mode and low-EMC mode, to meet the needs of different occasions.
5. long life and high reliability drive system to ensure the long-term stability of the curing lamp.
Four. Multiple interfaces are suitable for different integrated environments.
1., it is suitable for a variety of host computers such as PC, PLC, embedded systems, and interface design specifications.
2. Rich in functions, customers can quickly integrate into the device, but also for in-depth development, integrated into the control system UI.
Five. Manual and automatic control functions.
Simple manual control function is provided on the product, which can satisfy the requirements of switch and power regulation. It is suitable for product debugging, without PC or without integration with PC.
Customers can also perform automatic or manual control of all or part of the function through the signal interface.
Application of LED UV products
Application of QuickCure Series in digital inkjet printing industry:
The UV radiation intensity is 8-12W/cm2 and the line power is about 30W/cm. It is suitable for curing screen, offset plate, transfer printing and other printing, digital spraying, painting, coating and adhesion at low speed (less than 40-60m/min).
Multi PASS inkjet once scan curing!
Adjust the power according to the ink formula to achieve the best color performance.
High load operation can be used safely!
The quartz glass sheet can be easily replaced and cleaned to ensure the long-term curing quality. In the actual use of the users of the jet printer, the splashed ink droplets will stain the window glass of the UV lamp. After a few weeks, the irradiation transmittance of the UV light will be seriously affected, resulting in the phenomenon of poor curing. To solve this problem, engineers have invented a replaceable glass sheet structure that allows easy removal of glass, cleaning up ink, glass cleaning after only a few seconds to install in place.
Application of PowerCure Series in high speed spurting code industry:
1PASS black ink jet thickness 100um max. maximum curing speed of 160-200 M / min!
It is applied to plastic film spurting code printing, no distortion of material.
Compared to the original mercury lamp curing system, saving more than 90%!
Industrial standard design, long time high load operation can be assured of use!
PowerCure plus series
The UV LED curing system used in sheet-fed offset press has special advanced optical structure, which makes the curing lamp achieve high radiation intensity at the distance of 70-80 mm from the medium.
SuperCure series
Especially for high-speed coating curing products, UV radiation intensity can reach 25-30W/cm 2, line power is about 100W/cm.
Customized products
Special products can be customized according to customer needs, such as on-line curing system, special product curing system, stereo curing system, etc. Especially for the high-speed curing products of communication industry, the single-machine curing speed can reach 600M/Min., multi-group combination can support the current maximum coating curing 2500M/Min production line, but also support the future curing speed 3000M/Min. the latest production line, and energy consumption is only about one tenth of the original microwave electrodeless lamp!
